The FOXBORO FBM201E P0924TR is a high - performance analog input module designed for industrial control and monitoring applications. As a part of the Foxboro I/A Series, it plays a crucial role in data acquisition within distributed control systems (DCS).

This module is equipped with eight analog input channels, each of which is designed to accept a 2 - wire, 0 - 20 mA DC input from analog sensors. This makes it highly compatible with a wide range of industrial sensors, such as those measuring temperature, pressure, and flow. The module's primary function is to carry out signal conversion. It transforms the incoming electrical input signals from field sensors into a format suitable for seamless communication with the control system, specifically the field control processor (FCP).

One of the notable features of the FBM201E P0924TR is the galvanic isolation provided for each analog input channel. This isolation not only separates the channels from one another but also from the ground. In industrial settings where electrical interference can be a significant issue, this galvanic isolation greatly enhances the module's immunity to electrical noise, ensuring the integrity and accuracy of the input signals.

The module has a compact and rugged design, which is compliant with Class G3 standards per ISA standard S71.04. This means it can withstand harsh environmental conditions, making it suitable for deployment in various industrial environments, including those with high levels of humidity, dust, or vibration. Its exterior is made of durable materials that offer physical protection to the internal circuits, safeguarding the module against potential damage.

Internally, the FBM201E P0924TR employs sigma - delta data conversion on a per - channel basis. This advanced conversion technique enables high - accuracy analog - to - digital conversion. It can obtain a new analog input reading every 25 ms, providing real - time data updates. Moreover, the integration period is software - configurable. This allows users to optimize the module's performance according to the specific requirements of their applications. By adjusting the integration period, users can effectively remove process noise and power - line frequency noise, ensuring that the data transmitted to the controller is clean and reliable. During each time period, the module converts the analog inputs to digital values, calculates the average of these values, and then provides this averaged value to the controller for further processing.

Installation and maintenance of the FBM201E P0924TR are designed to be convenient. It can be mounted on a compact 200 series baseplate, and is attached to the baseplate using two screws. One of the key advantages is that the module can be removed and replaced without the need to disconnect the field device termination cabling, power, or communication cabling. This significantly reduces downtime during module replacement, contributing to the overall efficiency and productivity of the industrial process.

In summary, the FOXBORO FBM201E P0924TR analog input module is a reliable, high - performing, and user - friendly component that meets the demanding requirements of industrial process control. Its accurate data acquisition and signal conversion capabilities, combined with its rugged design and ease of maintenance, make it an ideal choice for a wide range of industrial applications.

FOXBORO FBM201e P0924TR analog input module

FOXBORO FBM201e P0924TR analog input module
