The Bentley 3500 - 22M is a transient data interface (TDI) module developed by Bentley Nevada, now part of GE Detection & Measurement. This module serves as a vital link between the 3500 monitoring system and Bentley Nevada System 1TM mechanical management software.

It combines the functions of the 3500/20 framework interface module (RIM) and communication processor features, like TDXnet. This allows it to continuously gather both steady - state and transient waveform data. The collected data is then transmitted via an ethernet link to the host software for in - depth analysis.

Typically installed in a 3500 rack, specifically in the slot adjacent to the power supply, it works in tandem with M - series monitors such as the 3500/40M and 3500/42M. For applications requiring triple modular redundancy (TMR), there's a TMR - configured 3500/22M TDI. Besides standard TDI functions, it also has a "monitor channel comparison function".

In terms of data collection, it has diverse capabilities. It can support up to four Keyphasor signals for the 3500 system. The number of active dynamic channels determines the supported speed range, and it can handle speed inputs that occur multiple times per rotation, up to 20 kHz. It collects start - up and shut - down data at pre - set speed and time intervals. Additionally, it captures alarm data, gathering waveform data before and after an alarm, as well as static value data at specific intervals around an event.

With a power consumption of 10.5 watts, it offers 10Base - T or 100Base - TX ethernet connectivity (with auto - sensing for 100Base - FX fiber - optic ethernet). Compact in size, with dimensions of 9.50 in x 0.96 in x 3.90 in and weighing 0.20 kg, it's suitable for various industrial setups. The module also has features like a rack reset button and LED indicators for pre - and post - alarm data, enabling real - time monitoring and alerting. Overall, the Bentley 3500 - 22M is an essential component for industrial automation, machinery monitoring, and effective mechanical management in sectors like power generation, petrochemicals, and manufacturing.

Bentley 3500-22M

Bentley 3500-22M

Bentley 3500-22M

Bentley 3500-22M
