GVC704AE01/5SHX1060H0001/3BHB003230R0101) Chinese Specifications

Protection Rating

IP23 (Dust and water resistant, suitable for industrial workshop environments)

Cooling Method

TEFC (Totally Enclosed Fan Cooled), thermal resistance as low as 0.8℃/W, excellent heat dissipation efficiency

Conversion Efficiency

≥92% (Utilizes PWM high-frequency switching technology, achieving 30% energy savings compared to traditional solutions)

3. Features and Applications

Features:

1. Highly integrated design reduces volume by 40% compared to traditional solutions, saving cabinet installation space; 2. Built-in 16-bit resolution ADC chip supports 0-10V/4-20mA analog inputs with 0.01% signal acquisition accuracy; enables millisecond-level motor speed adjustment via PID control algorithms; 3. Comprehensive protection functions including overvoltage, overcurrent, overtemperature, and ground fault protection; DC bus voltage monitoring circuit automatically triggers protection during abnormal input voltages; 4. Highly compatible, supporting rack mounting and DIN rail installation to adapt to various cabinet structures.

Application Scenarios: Widely used in heavy industries such as metallurgy (blast furnace fan control), chemical processing (reactor temperature control), energy, and mining. Compatible with high-voltage frequency conversion boards, power converters, motor drive systems, and other equipment to effectively enhance production efficiency and product yield.

III. ABB 3BHB003230R0101 Thyristor Module

1. Product Overview

The 3BHB003230R0101 is an ABB thyristor module specifically designed for high-voltage industrial control systems. Often paired with the 5SHX series modules, it serves as a core component in the IGCT/IGBT hybrid control series. Featuring high bufferless turn-off ratings, this module specializes in medium-frequency excitation machine control, enabling stable switching and current regulation in high-voltage circuits. It serves as a critical protection and control element in industrial drives and power systems.

2. Core Technical Parameters (Refer to Series Matching Parameters)

Parameter Item

Parameter Value/Description

Product Type

High-voltage thyristor control module

Core Function

Medium-frequency excitation machine control, high-voltage circuit switching control

Protection Features

Integrated overcurrent, undervoltage, ground fault, and thermal overload protection; supports motor start monitoring and load unloading functions

Compatible Series

Compatible with 5SHX series modules (e.g., 5SHX14H4502, 5SHX1060H0001), compatible with ABB high-voltage drive systems

Package Type

Industrial-grade high-voltage module packaging, compliant with high-voltage equipment installation standards

ABB GVC704AE01 5SHX1060H0001 3BHB003230R0101 Thyristor Module

ABB GVC704AE01 5SHX1060H0001 3BHB003230R0101 Thyristor Module

ABB GVC704AE01 5SHX1060H0001 3BHB003230R0101 Thyristor Module

ABB GVC704AE01 5SHX1060H0001 3BHB003230R0101 Thyristor Module
