ABB 500BOM01 1MRB150023R0002 control card

ABB 500BOM01 1MRB150023R0002 control card

1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

Inquire Now

Tags:

500BOM01

1MRB150023R0002

control card

Additional Information:

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283

Product Name:

ABB electronic overload relay module

(ABB Electronic Overload Relay Module)

Model number:

1SVR150023R0002 (Note: The 1MRB you provide is an older designation. The current standard model usually starts with 1SVR, but refers to the same product. 1MRB150023R0002 equivalent to 1SVR150023R0002)

Core model part: SBR (for Electronic Overload Relay module)

Main parameters:

Current range: 0.10-0.16A (This is the set current range of the module, usually set by the knob or dial code on the module)

Rated operating current (Ie) : 0.16A (maximum continuous operating current set value supported by the module)

Tripping grade: Class 10 (means the tripping time is less than 10 seconds under the setting current of 7.2 times. This is the response speed standard grade to protect the motor from the starting current.)

Contact Configuration:

Main circuit: None (the overload relay itself does not directly disconnect the main circuit current, and needs to pass through the contacter)

Auxiliary contact: 1 normally open (NO) + 1 normally closed (NC) (95-96/97-98) (for overload signal and control loop interlocking)

Control voltage: 24-230 V AC/DC (operating voltage range of auxiliary contact)

Installation: Designed for Snap-on Mounting on compatible ABB contactors (usually A-series contactors such as A9, A12, A16, A26, A30, A40, A50, A63, etc.).

Core functions:

Provide motor overload protection to prevent motor damage due to prolonged over-current operation.

Provides out-of-phase protection (three-phase imbalance protection).

Provides blocking protection.

It outputs fault signals through its auxiliary contacts (95-96 NC, 97-98 NO), which can be used to control loop interlocking, indicator lights or alarm systems.

Typical applications:

It is used to protect and control small three-phase AC motors, especially in applications with low current requirements.

Widely used in mechanical equipment, pump, fan, conveyor belt, compressor and other industrial fields.

Fit with contactor:

This module must be used with ABB A series contacters such as AF09, AF12, AF16, AF26, AF30, AF38, AF40, AF50, AF63 and other corresponding models.

It is clamped on the side of the contacter, and through mechanical linkage and electrical connection, the contacter performs the opening and closing of the main circuit, while the overload relay is responsible for detecting the current and commands the contacter to break when the fault occurs.
