FBM202 P0926EQ is A thermocouple input module in Foxboro I/A Series series, which supports various types of thermocouple signals (including K, J, T, E, B, R, S, etc.) to achieve high precision temperature measurement function. The modules are used in process control systems, especially for thermal process monitoring, industrial automation, chemical and power industry temperature acquisition requirements.

Main technical parameters

Description of project parameters

Input type Thermocouple input (K, J, T, E, B, R, S, N, etc.)

The number of input channels is 8 channels, and the isolated thermocouple input

Analog input range thermocouple type dependent (automatic cold end temperature compensation)

Accuracy (typical) ±0.1% reading ±1°C (depending on thermocouple type)

Isolation characteristic channels are completely isolated between channels and between power supply and channels

Cold end compensation Built-in cold end temperature compensation (CJC)

Input signal update rate 50 ms (per channel)

Operating temperature range 0°C ~ 60°C (standard module)

Mounting is mounted on a Foxboro FBM channel Baseplate

Communication with the I/A Series control system through the module bus communication

Module power supply through system backplane (24 VDC common bus)

Functional Features

Multiple thermocouple compatibility: supports a wide range of thermocouple standard types to meet various industrial temperature measurement requirements

Each channel independent isolation: each input channel electrical isolation, improve the system anti-interference ability and security

High precision measurement: built-in cold end compensation to ensure thermocouple measurement accuracy

Modular design: hot plugging module, support field rapid replacement and maintenance

Adaptation System: Fully compatible with Foxboro I/A Series control system for seamless integration

FOXBORO FBM202 P0926EQ 8-channel thermocouple/MV input interface assembly

FOXBORO FBM202 P0926EQ 8-channel thermocouple/MV input interface assembly
