ABB PFV0-102 is an auxiliary power module or extension module in ABB industrial automation systems, mainly used to provide stable power support or function expansion for control systems (such as PLC, inverter, servo drive, etc.). Its design compatibility is strong, common in the low power industrial equipment matching.

2. Core functions

Power distribution: The main power supply (such as AC 220V/380V) is converted to low-voltage DC (such as 24VDC) to power the sensors, I/O modules, communication units, etc., in the control cabinet.

Signal isolation: Through electrical isolation protection, reduce the influence of electromagnetic interference (EMI) on sensitive control signals.

Extension support: As an extension unit of PLC or drive system, increase the power output channel or auxiliary interface capacity.

3. Technical parameters (speculation)

Description of project parameters

Input voltage AC 100-240V ±10%, 50/60Hz

Output voltage DC 24V (typical value, multi-output may be supported)

Output power 60-100W (subject to the actual model)

Protection grade IP20 (standard protection installed inside the cabinet)

Operating temperature -25°C to +55°C (with derating use)

Communication interface without (pure power supply module) or optional communication terminals

4. Typical application scenarios

PLC system power supply: provide stable 24VDC power supply for the I/O module and communication module of ABB AC500 series PLC.

Frequency converter matching: with ACS550, ACS880 and other frequency converters, for external brake resistance or control circuit power supply.

Distributed control Cabinet: In remote I/O stations or field control boxes, it acts as a local power distribution unit.

5. Installation and compatibility

Installation: standard DIN rail installation (width about 50-80mm), suitable for compact control cabinet.

Compatible Devices:

ABB PLC series (such as AC500, AC800M).

ABB inverter series (such as ACS550, ACS880).

Third-party sensors, relays, etc. that support 24VDC input.

ABB PFV0-102 extension module

ABB PFV0-102 extension module

ABB PFV0-102 extension module
