FOXBORO FDC280 RH101FQ DCS module

1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

Inquire Now

Tags:

Additional Information:

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283

Technical parameters of FOXBORO FDC280 RH101FQ DCS module

Basic Features

Module type: Distributed control system (DCS) I/O module, usually used for process control.

Function: Support analog/digital signal input or output (depending on the configuration, need to confirm the model suffix).

Compatibility: Integration with FOXBORO's I/A Series or Evo systems for industrial automation environments.

Input/output specifications (specific functions need to be confirmed)

Analog input (AI):

Number of channels: 8 or 16 channels (isolated or non-isolated).

Signal type: 4-20mA, 0-10V, thermocouple, RTD, etc.

Accuracy: ±0.1% FS (typical value).

Digital input/output (DI/DO):

Signal type: dry contact, 24VDC level input or relay output.

Isolation: Isolation between channels or groups.

Communication and protocol

Communication interface: Support Foundation Fieldbus (FF), Profibus DP/PA or HART protocol (verification version required).

Data transmission rate: 31.25 kbps (FF H1), 1.5 Mbps (Profibus DP), etc.

Redundancy support: Module or communication redundancy (such as dual power/dual communication ports) may be supported.

Power supply requirements

Supply voltage: 24VDC (typical industrial power supply).

Power consumption: about 2-5W (depending on the number of activated channels).

Environmental parameters

Operating temperature: -40°C to +70°C (industrial grade).

Protection level: usually IP20 (need to be installed in the control cabinet).

Humidity: 5% to 95% non-condensable.

Mechanical specifications

Size: Meet FOXBORO standard module size (about 150mm × 100mm × 50mm).

Installation: DIN rail installation or gantry fixed.

Certification and Standards

Safety certification: CE, ATEX (explosion proof), IECEx (optional).

EMC: conforms to IEC 61326 (anti-interference in industrial environment).

The Foxboro™ DCS Field Device Controller 280 (FDC280) is a distributed, optionallyfault-tolerant, field-mounted controller that performs process control and alarmingfunctions according to a user-defined control strategy, as well as providing direct fielddevice integration without the need for additional Foxboro DCS Fieldbus Modules(FBMs).The primary purpose of the Field Device Controller 280 (FDC280) is deviceintegration, including interfacing Ethernet and Serial field devices, accessing data inthose devices for display, historization, and performing control tasks. The FDC280performs regulatory, logic, timing, and sequential control internally. It also performsalarm detection and notification.The FDC280 runs a dual-core CPU to provide two computational environments for theFDC280. Core 1 (Control Core) runs the FDC280’s control software and Foxboro DCSControl Network communications software. Core 2 (I/O Core) runs additional features,in this case, the device integration software.The FDC280 communicates directly with field devices that support the protocols listedin these PSSs:• EcoStruxure™ Foxboro™ DCS PROFINET IO-Controller Driver for Field DeviceController 280 (PSS 41S-3PROFIDR)• EcoStruxure™ Foxboro™ DCS Modbus Client TCP Driver for Field DeviceController 280 (PSS 41S-3FDCMBDV)• EcoStruxure™ Foxboro™ DCS Modbus Client RTU Serial Driver for Field DeviceController 280 (PSS 41S-3FDCMBRT)• EcoStruxure™ Foxboro™ DCS Triconex™ System Access Application Driver forField Device Controller 280 (PSS 41S-3FDCTSAA)• EcoStruxure™ Foxboro™ DCS OPC UA Client Driver for Field Device Controller280 (PSS 41S-3FDCOPC)• EcoStruxure™ Foxboro™ DCS EtherNet/IP Scanner Driver for Field DeviceController 280 (PSS 41S-3FDCIPDR)The FDC280 connects to the Control Network via standard fiber optic or copper 100Mbps Ethernet cables from network adapters installed on its baseplate.The FDC280 requires a host workstation with Foxboro DCS Control Core Servicessoftware v9.3 or later.The FDC280 is certified ISASecure EDSA Level 1.
