PROSOFT MVI69-PDPMV1 communication module
PROSOFT MVI69-PDPMV1 communication module
PROSOFT MVI69-PDPMV1 communication module
PROSOFT MVI69-PDPMV1 communication module
PROSOFT MVI69-PDPMV1 communication module
PROSOFT MVI69-PDPMV1 communication module
PROSOFT MVI69-PDPMV1 communication module

PROSOFT MVI69-PDPMV1 communication module

1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283


PROSOFT MVI69-PDPMV1 communication module


PROSOFT MVI69-PDPMV1 communication module


Description


The PROFIBUS DPV1 master station module is a powerful communication interface for Rockwell Automation ® CompactLogix/MicroLogix® processors. Developed under license from Rockwell Automation, the module features proprietary backplane technology for powerful data exchange with CompactLogix/MicroLogix processors.


The module supports complete master station specifications according to IEC 61158 standards. Acyclic parameter data can be transmitted via Class 1 or Class 2 DPV1 services, enabling the processor to easily communicate with slave devices that support the PROFIBUS DPV0/V1 protocol.


This module is the input/output module between the PROFIBUS network and the CompactLogix/MicroLogix processor. The data transfer of the processor is asynchronous from the I/O data transfer on the PROFIBUS network.


peculiarity


 Single slot - Compatible with 1769 backplane


 modules are identified as input/output modules, have access to processor memory, and transfer data between the processor and the module


 Ladder logic is used for data transfer between module memory and processor controller labels. Sample file of ladder diagram containing AOI


 Get the Configuration data from the ProSoft Configuration Builder software, which defines the PROFIBUS network, and then download the configuration into the module via the serial port of the PC.


 Supports CompactLogix and MicroLogix 1500 LRP controllers in addition to 1769-QBFC1B, 1769-L16x, and 1769-L18x


Functional specification


The inRAx PDPMV1 PROFIBUS master module acts as a PROFIBUS network scanner, transmitting input and output data between the PROFIBUS device and the processor data memory via the backplane.


 Use the included ProSoft Configuration Builder (part No. PSW-PCB) to configure the master bus view


 project dedicated GSD file import library


 Monitors and modifies process data and DPV1 acyclic data


 Multipoint transmission with other compatible devices on the PROFIBUS DPV1 network


 Automatic project documentation


 Automatic bus parameter calculation


 Online slave station diagnosis


 supports all standard baud rates up to 12 Mbps


 Support Extended diagnostic data (DPV1)


 One rack can house multiple master stations


 CRC verifies the consistency of the slave configuration with the processor


 Master status LED for operation, network communication, master token retention, and network configuration


 includes FDT/DTM PROFIBUS Master Station Transmission communication DTM software (Part No. PSW-CDTM-PDPM)


PROFIBUS master station specifications


 Up to 125 slave stations can be connected via Repeaters


 Up to 1536 bytes of loop input and 1536 bytes of output data


 Supports extended diagnostic data


 RS-485 optical isolated PROFIBUS interface with onboard DC-DC converter


 acyclic communication (DPV1), read, and write


 Alarm Processing (DPV1)


 Supports synchronization and freezing commands


 Read and write operations that comply with PROFIdrive 3.1 standards are supported


 Supports multicast and broadcast packets (DPV1)


PROFIBUS Main port


 DB-9F Optical isolation RS-485


 Ready, run, Error, and token LED indicators


 PROFIBUS DPV1 RS-485 interface with 9-pin D-housing female connector and isolated optocoupler

PROSOFT MVI69-PDPMV1 communication module


PROSOFT MVI69-PDPMV1 communication module(图1)

PROSOFT MVI69-PDPMV1 communication module

PROSOFT MVI69-PDPMV1 communication module(图2)


PROSOFT MVI69-PDPMV1 communication module


PROSOFT MVI69-PDPMV1 communication module(图3)


PROSOFT MVI69-PDPMV1 communication module

PROSOFT MVI69-PDPMV1 communication module(图4)


PROSOFT MVI69-PDPMV1 communication module


PROSOFT MVI69-PDPMV1 communication module(图5)


PROSOFT MVI69-PDPMV1 communication module


PROSOFT MVI69-PDPMV1 communication module(图4)


PROSOFT MVI69-PDPMV1 communication module
