NI Ettus USRP X410

summarize

The NI Ettus USRP X410 is a high-performance, multi-channel software-defined radio. Designed for a frequency range of 1 MHz to 7.2 GHz and adjustable up to 8 GHz, SDR uses a two-stage superheterodyne architecture with four separate TX and RX channels, each with an instantaneous bandwidth of 400 MHz. Digital interfaces for data offloading and control include two QSFP28 interfaces with 100 GbE support, one PCIe Gen3 x8 [1] interface, and standard command, control, and debugging interfaces: USB-C JTAG, USB-C Console, Ethernet 10/100/1000. The USRP X410 is an all-in-one device built on Xilinx Zynq Ultrascale+ ZU28DR RF System-on-chip (RFSoC) with built-in digital up-conversion and down-conversion and on-board soft decision Forward error correction (SD-FEC) IP.

Use the software of your choice

The NI Ettus USRP X410 fully supports the popular open source USRP Hardware Driver (UHD) version 4.1 or later [2]. UHD 4.1 is designed to support the big data mobility requirements that come with 400 MHz bandwidth and on-board multiple channels. The USRP X410 supports open source SDR design flows such as C/C++ and GNU Radio, as well as LabVIEW FPgas [1]. Unlike other RFsoc-based systems, the USRP X410 is fully portable to your previous UHD design, requiring only a simple recompilation to take full advantage of high performance features.

Networked/independent operation

Because the USRP X410 is built on a ZU28DR RF System on Chip (RFSoC) device, it is equipped with a quad-core ARM Cortex-A53 processing subsystem with up to 1.2 GHz for standalone application requirements. In addition, the RFSoC includes a dual-core ARM Cortex-R5 real-time processing unit for onboard monitoring and control.

Built-in IP

The on-board RFSoC on the USRP X410 contains more than twice as many FPGA programmable logic resources as the previous generation X-Series USRP devices. In addition, the ZU28DR is equipped with eight soft-decision forward error correction (SD-FEC) hard IP cores, which are ideal for wireless communication systems. Given the high-speed nature of RFSoC's built-in ADCs and Dacs, Zynq devices feature eight digital up-conversion and digital down-conversion IP cores for fast in-band re-tuning or signal attenuation.

Multiple radio synchronization

The built-in GPSDO (GPS calibrated oscillator) or 10 MHz reference and 1 PPS (pulse per second) input signal interface enables multi-radio clock and timing synchronization operation. Multi-radio phase alignment and phase coherence operations are not supported because the USRP X410 does not support RF chain LO import and export functions.

[1] PCIe Gen3 x8 is supported only by the NI-USRP and LabVIEW FPGA design flow

[2] UHD 4.2 or later supports 100 GBE

PXI vector signal receiver and transmitter

Combined with the vector signal analysis instrument based on FPGA device, vector signal generation and signal processing and the control.

PXI vector signal collect hair instrument (VST) combines the electrical architecture of software radio is flexible and RF instruments of high performance. You can use the VST to test various bees nest and wireless standards, and can easily extend the VST 3 slot 3 u PXI Express shape structure, to support multiple input multiple output (MIMO) configuration. VST software is based on LabVIEW FPGA and provides a good starting point for application development, including application IP, reference design, norm and LabVIEW project norm.

Product Selection: NI PXI vector signal receiver and transmitter

Part number I/O Type RF Generator Instantaneous bandwidth RF Generator Frequency Range RF Analyzer Frequency Range RF Analyzer Instantaneous bandwidth generator Tuning time (Typical)

PXIe-5644 782376-01 RF 80 MHz 65 MHz to 6 GHz 65 MHz to 6 GHz 80 MHz 0.95ms

PXIe-5645 782377-01 RF Baseband 80 MHz 65 MHz to 6 GHz 65 MHz to 6 GHz 80 MHz 3.7 ms

PXIe-5645 782377-01 RF Baseband 80 MHz 65 MHz to 6 GHz 65 MHz to 6 GHz 80 MHz 3.7 ms

PXIe-5646 782952-01 RF 200 MHz 65 MHz to 6 GHz 65 MHz to 6 GHz 200 MHz 1.8 ms

PXIe-5820 783967-01 Baseband 1 GHz 0 MHz to 500 MHz 0 Hz to 500 MHz 1 GHz 0.38 ms

PXIe-5830 787047-01 RF 1 GHz 5 GHz to 12 GHz 5 GHz to 12 GHz 1 GHz -

PXIe-5831 786856-01 RF Millimeter Wave 1 GHz 5 GHz to 31.3GHz 37 GHz to 44 GHz 5 GHz to 44 GHz 1 GHz -

PXIe-5831 786853-01 RF 1 GHz 5 GHz to 21 GHz 5 GHz to 21 GHz 1 GHz -

PXIe-5832 787728-01 RF Millimeter Wave 1 GHz 5 GHz to 44 GHz 5 GHz to 44 GHz 1 GHz -

PXIe-5841 786982-01 RF 1 GHz 9 kHz to 6 GHz 9 kHz to 6 GHz 1 GHz 380 us

PXIe-5841 785832-01 RF 1 GHz 9 kHz to 6 GHz 9 kHz to 6 GHz 1 GHz 175 us

PXIe-5841 788842-01 RF 1 GHz 9 kHz to 6 GHz -- 380 us

PXIe-5841 788843-01 RF -- 9 kHz to 6 GHz 1 GHz 380 us

PXIe-5841 788844-01 RF 1 GHz 9 kHz to 6 GHz -- 175 us

PXIe-5841 788845-01 RF -- 9 kHz to 6 GHz 1 GHz 175 us

PXIe-5842 788565-01 RF 2 GHz 50 MHz to 23 GHz 50 MHz to 23 GHz 2 GHz 230 us

PXIe-5842 788565-02 RF 2 GHz 50 MHz to 12 GHz 50 MHz to 12 GHz 2 GHz 230 us

PXIe-5842 788565-03 RF 1 GHz 50 MHz to 8 GHz 50 MHz to 8 GHz 1 GHz 230 us

PXIe-5842 788566-02 RF Millimeter Wave 2 GHz 200 MHz to 23 GHz 22.5 GHz to 54 GHz 200 MHz to 23 GHz 2 GHz -NI NI-5600
