1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283



The GE VMIC VMIVME-2510B Input/output module is a high-performance module belonging to the VMIC Megamodule series with the following main features and functions:


General programming features:

The VMIVME-2510B is a 64-bit TTL input/output module in which the direction of each 8-bit port can be individually programmed, providing users with flexible configuration options to adjust the allocation of inputs and outputs to their specific needs.

Receiver capacity:

The module has a receiver capability of 64mA (15mA source), ensuring stable signal reception.

Address decoding function:

The module has the function of independent board address decoding of control register and data register, which helps to realize more efficient memory management and data access.

Fault detection and isolation:

The module has built-in test logic to support fault detection and isolation. Specific hardware has been designed to support built-in test functions, with offline and online fault detection and isolation capabilities. When there is a fault on the board, the front panel fault LED will light up to indicate the fault status.

I/O connectors and data transfer:

The module uses a highly reliable DIN type I/O connector and supports 8-bit, 16-bit and 32-bit data transmission to meet the data transmission requirements in different application scenarios.

Memory and address mapping:

The subsystem can be configured with consecutive I/O addresses to save memory. The module also designs two sets of board address switches to provide efficient memory address mapping and I/O addresses for CSR. By setting the CSR address switch, all CSRS in the various boards in the system can be mapped to a continuous memory location.

Application field:

This input/output module has a wide range of applications in industrial automation, control systems, embedded systems and other fields, providing reliable and efficient input/output functions, and supporting flexible address mapping and fault detection.

Overall, the GE VMIC VMIVME-2510B input/output module is a powerful, high-performance module with a high degree of flexibility and reliability to meet the needs of a wide range of industrial automation and control applications.
