The BENTLY 133396-01 vibration sensor is a component or module in a vibration monitoring system manufactured by Bently Nevada. The following are the details and features of the BENTLY 133396-01 vibration sensor:

Function overview:

The sensor is a 4-channel displacement monitor that receives input from the Bentley displacement sensor.

Various vibration and displacement measurements are generated after the signal is processed.

The processed signal is compared with a user programmable alarm setting point.

Main features:

Multi-channel design: Has 4 channels, allowing simultaneous monitoring of multiple parameters or positions.

Highly configurable: Each channel can be configured using 3500 frame configuration software to achieve radial vibration, axial displacement, differential expansion, axis eccentricity and many other functions.

Alarm and notification functions: The system usually has an alarm function to send notifications to operations personnel when abnormal conditions are detected.

Data Analysis and processing: The Vibration analysis module is used to analyze and process vibration data to identify vibration anomalies and mechanical problems.

Technical parameters:

Sensitivity: For radial vibration and axial displacement, the sensitivity can reach 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil).

Power requirements: Suitable for a variety of power options, including AC power and DC power, the specific input voltage range varies according to the selected power type.

Hardware interface:

Front panel LED indicators, including the OK LED, TX/RX LED, and Bypass LED, indicate the running status, communication status, and bypass mode.

Sensor buffer output: The front board should have a coaxial connector in each channel, and each coaxial connector has short circuit protection.

Application field:

The BENTLY 133396-01 vibration sensor is widely used in fields where vibration, displacement and other critical parameters of rotating machinery need to be monitored, such as industrial manufacturing, energy, petrochemical, etc.

Please note that the above information is based on currently available reference articles and materials, and specific technical parameters and application scenarios may vary by product version and configuration. For more detailed requirements or questions, you are advised to contact Bently Nevada's official channels or technical support directly for accurate information.

BENTLY 133396-01 Vibration sensor

BENTLY 133396-01 Vibration sensor

BENTLY 133396-01 Vibration sensor

BENTLY 133396-01 Vibration sensor
