The GE IS220PTCCH1A thermocouple module is a high-performance thermocouple input module manufactured by General Electric (GE) for use in Mark VI/Mark VIe systems. Here is a detailed description of the module:
Product Description:
The IS220PTCCH1A is a thermocouple input module designed and manufactured by General Electric for the management and control of gas, hydraulic and steam industrial turbine systems.
Equipped with an internal BPPx processor board and acquisition board for thermocouple input functions, the module supports E, J, K, S and T standard thermocouples as well as mV inputs spanning -8 to 45 mV.
Application features:
Suitable for simplex, duplex and triple modular redundancy applications.
E, J, K, S, and T thermocouples can be grounded or ungrounded and can be located up to 984 feet from the turbine I/O panel.
Cable resistance must be maintained at a maximum of 450 Ω.
Technical indicators:
The maximum software error/consistency error is 0.25 degrees Fahrenheit.
The common-mode voltage is +/ -5 V, and the AC common-mode rejection is 100dB@50/60Hz.
Includes 250 mV RMS @ 50/60 Hz (+/-5%) normal mode suppression and high/low hardware and software limit checks.
Environmental adaptability:
Designed to operate in ambient conditions from -22 to +149 degrees Fahrenheit.
Provides multiple self-diagnostic capabilities, including power-on self-tests of flash memory, RAM, processor board hardware, and Ethernet ports, as well as continuous monitoring of its internal power supply.
Anti-static measures:
Should be handled with care, and implement anti-static procedures to prevent the accumulation and release of static electricity to damage the board.
The circuit board should be kept in an anti-static bag or box until it can be installed.
You are advised to wear an ESD wrist strap during installation.
Packaging and configuration:
The amount of packaging used determines the number of thermocouple inputs. For example, the number 1 IS220PTCCH1A offers 12 thermocouple inputs and number 2 offers 24, while specific configurations are available for TMR (Triple modular Redundancy) configurations.
Additional information:
The module is an integral part of GE's Mark VI/Mark VIe system, which provides efficient and accurate thermocouple input capabilities for industrial turbine systems.
Overall, the GE IS220PTCCH1A thermocouple module is a powerful, stable and highly reliable thermocouple input module suitable for the thermocouple input needs of a variety of industrial turbine systems.
GE IS220PTCCH1A THERMOCOUPLE MODULE
