The Bently 350045 position monitor is a feature-rich 4-channel instrument designed to receive and process input signals from a variety of sensors. Including but not limited to proximity sensors, rotary position sensors (RPT), DC linear variable difference sensors (DC LVDT), AC linear variable difference transformers (AC LVDT), etc. Here is a detailed overview of the Bently 350045 position monitor:

Main functions and applications:

Axial (thrust) position monitoring

Differential extension (including standard single slope, non-standard single slope and double slope differential extension)

Casing expansion monitoring

Valve position monitoring

Provides a comparison of continuous monitoring parameters with configured alarm setpoints to drive alerts

It is suitable for vibration monitoring of large and medium-sized rotating machinery such as steam turbine, compressor, fan, water pump, coal mill, gear box, motor, etc. It is widely used in steel, electric power, metallurgy, chemical industry, petrochemical industry and so on

Sensor input and signal regulation:

Accepts input signals from a variety of sensors

The input signal is adjusted and the adjusted signal is compared with the user programmable alarm Settings

Programming and configuration:

Each channel was programmed using 3500 Rack configuration software

The monitor channels are programmed in pairs to perform up to two functions at a time

Channels 1 and 2 perform one function, while channels 3 and 4 perform another (or the same) function

Only channels 3 and 4 can achieve shell expansion monitoring

Technical specifications:

Sensor sensitivity:

Axial position: 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)

Differential expansion: 0.394 mV/μm (10 mV/mil) or 0.787 mV/μm (20 mV/mil)

Gradient differential expansion: 0.394 V/mm (10 mV/mil) to 7.874 V/mm (200 mV/mil)

Complementary input differential expansion: 0.394 V/mm (10 mV/mil) to 3.937 V/mm (100 mV/mil)

Sensor power supply:

Proximitor or RPT: -24 volts DC

DC LVDT: +15 volts DC

AC LVDT: 2.3Vrms 3400Hz sine wave

Product size and weight:

Dimensions (H x W x D) : 241.3 mm x 24.4 mm x 241.8 mm

Weight: 0.91 kg

Input/output module:

Multiple input/output (I/O) module options are available to meet the needs of different measurement types and sensor inputs

In summary, the Bently 350045 position monitor is a highly modular and flexible device capable of receiving and processing input signals from a variety of sensors, providing a variety of position monitoring and alarm functions, and is widely used in a variety of large and medium-sized rotating machinery vibration monitoring and protection.

Bently 350045 position monitor

Bently 350045 position monitor

Bently 350045 position monitor
