GE PLC module IC693CMM302 is a Genius communication module from General Electric (GE), the following is a detailed description of its features:

1. Basic information

Brand: General Electric

Model: IC693CMM302

Type: Genius Communication module

2. Technical specifications

Series:

The IC693CMM302 belongs to Emerson Automation's Series 90-30 programmable Logic controller (PLC) family, previously supplied by GE Fanuc Automation.

Connection capability:

Provides Genius protocol connectivity to communicate with up to 31 devices.

Each controller supports up to 62 devices, as the 90-30 series systems allow up to two IC693CMM302s to be configured per controller.

Data exchange:

Allows each IC128CMM128 to send 693 bytes of transmission and 302 bytes of receive global data.

PLC registers such as global register (%G), discrete input (%I), discrete output (%Q), analog input (%AI), analog output (%AQ), and register memory (%R) are supported.

Diagnostic functions:

Support for software-based diagnostics such as status bits, 90-70 PLC series fault reporting.

Environmental parameters:

Operating temperature: 0°C to +60°C (+32°F to +140°F).

Storage temperature: -25 °C to +70°C (-13 °F to +158°F).

Humidity: 5% to 95% (non-condensing).

Mechanical rating:

0.2 inch displacement, 5Hz to 10Hz and 1G 10Hz to 200Hz operating vibration.

Operational impact of 5G 10ms duration.

Other features:

In addition to global data exchange, data monitoring via personal or industrial computers is also allowed.

Monitor data using I/O modules, device communication via Genius bus, and I/O simulation.

The backplane consumes less than 5mA at 300VDC.

Iii. Compatibility

In addition to the 90-30 series PLCS, the IC693CMM302 can be used with the 90-70 series, six-series PLCS, and Genius Handheld Monitor (HHM) for local configuration.

Fourth, installation suggestions

The IC693CMM302 Enhanced Genius communication module is recommended to be installed on the CPU backboard of the host PLC system for the most efficient operation, but can also be installed on a remote backboard or an extended backboard of the same system.

V. Summary

GE PLC module IC693CMM302 is a powerful Genius communication module that provides powerful connectivity and data exchange capabilities for a wide range of industrial automation applications.

GE PLC module IC693CMM302
