GE IC660BBD022 Circuit Enabled Source I/O module is a distributed I/O module from GE. The specific features and parameters are as follows:
Overview:
IC660BBD022 is a module that supports the Genius protocol and belongs to the Genius I/O Block family.
The module is an independent single-node I/O station with sixteen (16) I/O circuits that support source wiring configurations.
Electrical parameters:
Operating voltage: 24/48 VDC.
The input channel accepts 12/24 VDC nominal voltage and has a start-up delay of 1.7 ms.
Output channels Each circuit generates 2 amps of current with a maximum on-delay of 1 millisecond.
Functional features:
Each channel can be configured as input and output for data exchange via Genius I/O bus terminals.
Allows communication between modules such as GE programmable logic and automation controllers (PLCS/PACs), bus controllers, PC interface modules, Human machine interfaces (Hmis) and third-party devices.
With diagnostic functions and safety measures, it can easily detect errors such as overload, overheating, short circuit, no load and switch failure.
The operation of the module can be configured locally using the Handheld Monitor (HHM) via the HHM port mounted on the top of the terminal component, or remotely using the programming software of the main controller.
Physical characteristics:
Panel mounted stand-alone devices, with open housing, must be installed within the housing to provide adequate protection against industrial contaminants.
Can be installed remotely, with a maximum distance of 7,500 feet from partner equipment.
Allows Daisy chains to connect other I/O modules to form Genius I/O networks.
It is small, easy to carry, and saves panel space. The dimensions are 8.83 inches high, 4.42 inches deep, and 3.56 inches wide.
Application scenario:
It is suitable for industrial automation systems requiring efficient data exchange and remote communication, such as manufacturing, energy management, water treatment and other fields.
Other configuration:
The input/output of the module is enabled and the unit determines that the LED lights light up when the module is active.
The load current is 2 amps and is used with 2-wire and 3-wire sensors.
Intelligent and easy to configure as a sensor or actuator device.
Additional configurable features include output power defaults, optional input filtering times, and output pulse testing.
Through the above information, we can see that the GE IC660BBD022 circuit enables source I/O modules to play an important role in industrial automation systems, providing efficient and reliable data exchange and remote communication capabilities.
