ABB's EI813F 3BDH000022R1 input and output module, namely Ethernet module, is mainly used in industrial automation systems, data communication, remote control and monitoring, data acquisition and processing, and building automation. Here are some details about the module:

Technical specifications:

Supports 10BaseT (Twisted pair) Ethernet connection.

Software version requirements: V7.1SP2a or later is mandatory.

It is usually used with PM 802F or PM 803F and does not contain a battery.

Application field:

Industrial automation: as part of the control system, it is used for data communication and information transmission, and can be used in conjunction with controllers such as PLC (programmable logic controller) or DCS (distributed control system) to realize the monitoring and control of industrial equipment and processes.

Data communication: It is widely used in the industrial field for data communication between devices, transmitting data and information through the Ethernet network to achieve real-time monitoring and data exchange.

Remote control and monitoring: Through the Ethernet module, the control and monitoring of remote devices and processes can be achieved, which is particularly useful in trans-geographical or distributed control systems.

Data acquisition and processing: Ethernet modules can be used for data acquisition and processing to aggregate and process data from different devices and sensors to provide comprehensive information and decision support.

Building automation: In building automation systems, Ethernet modules can be used to control and manage building facilities, such as lighting, air conditioning, security, etc.

Energy management: Ethernet modules can be used in energy management systems to control and monitor energy equipment and improve energy efficiency.

Performance characteristics:

High energy efficiency: the typical energy efficiency reaches 96.5%, exceeding the 80 plus titanium gold standard.

Compact shape: 1RU shape size, high power density, up to 30W/in³.

Power supply stability: 48 VDC constant power supply, output voltage can be set between 42 V - 58 VDC.

Protection mechanism: It has the functions of output overvoltage and overload protection, AC input overvoltage and undervoltage protection, and overtemperature warning and protection.

Redundancy design: Support redundancy, parallel operation, with source load sharing function, improve the reliability and stability of the system.

Standard compliance: Dual channel, redundant I2C serial bus compliant with PMBus specifications, and standards such as EN/IEC 61000-3-2 and EN 60555-2.

Please note that the above information is for reference only and you are advised to consult the relevant product manuals or ABB's official technical support if necessary.

ABB EI813F 3BDH000022R1 Input and output module
