GE PMC-0247RC-282000 350-93750247-282000F

GE PMC-0247RC-282000 350-93750247-282000F

PMC Serial ATA Hard Disk Drive ModuleFeatures• Offers Enterprise Class storage forEmbedded Computing• 5-year HDD Product Lifecycle available forspecified rotating media• Standard and continuous operation drives(24x7, 8760 hours/year)• Extended shock and vibration option formaximum robustness• Extreme altitude operation possible up to16,400 feet available• Support for SATA II 300 MByte/s interfaces• Support for a programmable externalflash for BIOS expansionThe PMC-0247RC is a Serial ATA hard diskdrive module in PMC form factor, designedfor use with single board computers witha PMC site and carrier boards from GEFanuc Intelligent Platforms and other thirdparty manufacturers. Universal signalingsupport allows installing the modules inany available 3.3 V or 5.0 V PMC site. ThePMC-0247RC uses a 2.5 inch hard diskdrive and has a maximum capacity of160 GBytes.• Supports 32/64-bit, 133 MHz maximumPCI-X interface• Rotating Media with 80 GByte, 120 GByteand 160 GByte capacities(see ordering options)• Solid state drives with 16, 32 and 64 GBytecapacities (contact factory)• Compliant with VITA 39 Specification• Operating system support for Windows®2000, Windows XP, Red Hat Linux® Enterprise 4.0, and VxWorks® versions 5.4

SpecificationsForm Factor• PMCPower Requirements• Supplied through the PMC site connectors on the host• Power requirements are drive-dependentEnvironmentalOperating Temperature- SATA standard operation: +5 to +55 C- SATA continuous operation: +5 to +40 C- SATA Solid State: 0 to +70 CStorage Temperature-40 to +85 CRelative Humidity5% to 95%, noncondensingMTBF• 452,149 hours standard operation• 282,149 hours continuous operationRegulatoryThe PMC-0247RC has been tested to and found to meetthe requirements of the following standards.• European Union (CE Mark) - EN55024 - EN55022 Radiated Emissions Class A - EN61000-4-2 (ESD) - EN61000-4-3 (Radiated Immunity) - EN61000-4-8 (Power Frequency Magnetic Fields)• United States - FCC Part 15, Class A• Canada - ICES-003, Class A• RoHS 6/6: European Community Directive 2002/95/ECBlock DiagramSide ViewOrdering InformationPMC-0247RC - ABCDEFA = SATA Interface 2 = SATA II (3.0 Gb/s)B = Hard Disk Drive Capacity 2 = 80 GB HDD 3 = 160 GB HDD (5400 RPM)4 = Reserved 5 = 120 GB HDD (5400 RPM) 6 = 120 GB HDD (7200 RPM) 7 = 160 GB HDD (7200 RPM)Serial ATA I Hard Disk DrivePCI-X toSerial ATAControllerPMC Connectors4 MbExternalFlashSATA I33/64-bit/133 MHzmaximum0.5125 mm0.7875 mmNOTE: The PMC-0247RC violates the PMC specification for top and bottom maximum component height by 0.5125 mm and 0.7875 mm respectively.C = Operating Mode1 = Standard mode 2 = Extended dutyD = Solid State Drive0 = No SSD 1 = 16 GB SSD 2 = 32 GB SSD 3 = 64 GB SSDE, F = 0 (Options reserved for future use

GE PMC-0247RC-282000 350-93750247-282000F
