Evertz 7800 frame + 1x 24x2 duo and 2x 32x2 duo 7687vipa32-duo-3g-din multiviewe

Evertz 7800 frame with 1x 24x2 duo and 2x 32x2 duo 7687vipa32-duo-3g-din multiviewers

NOTE these multiviewers were only installed from new in 1 studio so are in excellent working condition.

Fully tested with 3G and HDSDI input signals,  HDSDI and DVI outputs etc

Main frame is 7800fr-Qt with fans at front

2x 7800PS-QT power supplies

2x 7867vipa32-duo-3g-din   advanced 3G / HDSDI / SDI  multiviewers with dual head (duo),

32x din inputs for video and HDSDI and DVI outputs for each head.

1x 7667vipa24-duo-3g-dinadvanced 3G / HDSDI / SDI  multiviewers with dual head (duo), with 24x inputs, 2x outputs (HDSDI / DVI)

From EVERTZ

The VIP Advanced DUO is the most advanced compact multi-image display processor technology available. It supports up to 3Gb/s SDI inputs and up to two unique display outputs. The VIP-A DUO takes compact multi-image display to the next level.

 The VIPA-DUO inputs are auto-sensing SDI, HDSDI, and 3Gb/s (SMPTE ST 424). Each VIP-A-DUO input can be displayed in any size, position or aspect ratio on any display. Both display outputs from the VIP-A-DUO are provided over DVI and HD-SDI, which are available simultaneously. The VIP-A-DUO provides the best quality input reproduction, borrowing the latest in video processing technologyrnfrom Evertz® industry acclaimed conversion products.

FEATURES

Accepts 32 (VIPA32-DUO) inputs with embedded audio

Uses Evertz® next generation image processing technology, which is the same technology used in conversion products

Auto-sensing HD/SD and 3Gbps (SMPTE ST 424) inputs (3G version)

Supports display resolutions of up to 1920x1200p on both outputs simultaneously

Allows for full screen viewing of any input on both outputs

Supports both DVI and HD-SDI outputs (active simultaneously)

Provides support for dynamic under monitor displays and tallies from routerand switcher • Supports advanced on screen graphics, including analog clocks, transparencycontrol of objects, raised bezels and borders, drop shadows, and bitmapbackgrounds• Supports true type font including non-Latin alphabets• Built-in graticule generator, user defined per window

 Enables the decoding and display of VITC/ATC (SMPTE ST 12-1, SMPTE ST12-2) timecode• Devices can be easily cascaded together to expand the total number ofimages on the displays• Built-in video, audio, and data fault monitoring with on screen fault notification

 VistaLINKm -

capable for configuration and monitoring via SNMP•

Minimal processing delay (1 frame)• Real time control of display outputs via Maestro

 On-screen display of level and phase bars (8 channels)

Capable of monitoring UHD input signa
