1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283


GE IC698CMX016-ED VMIVME-5567-000 350-005567-000 E module is a control memory switch module with specific functions and specifications. Here are the details and features of the module:


Basic information:

Brand: GE (General Electric)

Model: IC698CMX016-ED VMIVME-5567-000 350-005567-000

Type: Control memory switch module

Platform: PACSystem RX7i Platform (now part of Emerson Automation, formerly manufactured by GE Intelligent Platforms)

Main functions:

The module is primarily used to provide deterministic sharing of data between PLCS and compatible devices via fiber optic networks. It uses reflective storage technology to achieve this function.

Technical specifications:

Storage: 16MB SDRAM reflective memory with parity check.

Operating voltage: +5VDC, supplied by the power supply.

Current requirement: 1.8 amps.

Communication interface: An LC fiber port that supports transmission speeds of 2.12 Gbaud over multimode fiber media over a maximum distance of 300 meters or 984.25 feet, and supports dynamic packet sizes ranging from 4-64 bytes.

Network transfer rate: The maximum network transfer rate is 43 MB/ s (4-byte packets) to 174 MB/ s (64-byte packets).

Network nodes: Capable of communicating with up to 256 nodes per network.

Installation and connection:

It needs to be installed on the mainframe rack and connected to slot 3 or 4.

Compatible with VMIC 5565 series reflective storage device network.

Status indicator:

The front panel is equipped with various LED status indicators, such as OK, Configuration, own data and signal detection, to display the module's operation and communication status.

Configuration requirements:

It must be installed on an RX7i CPU with firmware version 2.00 or later and an RX7i CPU rack with a power supply.

Configure using Proficy Machine Edition - Logic Developer PLC 4.5 or later.

Physical characteristics:

Specification: 565852 (unit unclear, may be mm)

Color: Black

Weight: 1.56kg

Origin: USA

Price and Purchase:

Prices may vary depending on the event the item is participating in, the quantity purchased or the specifications selected.

The place of shipment is usually Shanghai and other places.

This module plays a key role in industrial automation and control systems, providing efficient and stable data sharing between PLCS and compatible devices.


GE IC698CMX016-ED VMIVME-5567 Control memory switch module

GE IC698CMX016-ED VMIVME-5567 Control memory switch module(图1)
