The MTL838B-MBF multiplex temperature converter is a product from MTL Instruments with a range of features and functions to meet the needs of different application scenarios. The following is a detailed introduction to the MTL838B-MBF multiplexer:

Product Overview:

The MTL838B-MBF is a multichannel temperature converter capable of converting multiple temperature signals into standard signals (e.g., 4-20mA) for easy use in monitoring and control systems.

Main features:

Multi-channel input: Supports the connection of multiple temperature sensors, and each channel can be configured independently.

Temperature range: Suitable for a certain temperature range, the specific range depends on the product specification.

Signal conversion: The temperature signal is converted to a standard signal, usually 4-20mA.

Explosion-proof design: For some special environments, there may be explosion-proof design to adapt to higher risk places.

Communication interface: Supports communication with other devices and control systems for data transmission and monitoring.

High accuracy: High precision temperature measurement and conversion to ensure accurate data acquisition.

Flexible configuration: It has flexible configuration options to adapt to different application requirements.

Power supply: Provide the appropriate power supply to ensure the normal operation of the equipment.

Performance parameters:

System configuration: Each MTL831B can be connected to 16 thermocouple signals, and each MTL838B-MBF can be connected to two MTL831B signals.

Communication protocol: communicates with DCS over MODBUS.

Environmental adaptability: The ambient temperature range of the MTL831B transmitter unit is -20 ° C to +60 ° C, and the storage temperature range is -40 ° C to +80 ° C.

Conversion accuracy: The conversion accuracy of the MTL831B is 0.1%.

Installation and configuration:

The MTL838B-MBF provides MODBUS serial data output and can be configured from a personal computer, including thermocouple, thermal resistance modeling, safety driver, high and low alarm, and other operating parameters.

Up to 31 receivers can be attached to one RS485 communication line connected to the main system, which can be controlled by any suitable MODBUS master station or can be attached to the same RS485 line with other MODBUS slaves.

Application scenario:

The MTL838B-MBF multichannel temperature converter is widely used in scenarios where multiple temperature signals need to be monitored and controlled, such as chemical, electric power, metallurgy and other industrial fields.

In summary, the MTL838B-MBF multiplex temperature converter is a powerful, flexible and superior device that can meet the needs of a variety of complex applications.
