Eaton's DPM-MC2 Communication Card is a dedicated communication card designed for MICRO PANEL MC2 series devices. The following is a detailed description of the communication card:

1. Scope and compatibility

The card is only available for MICRO PANEL MC2 series devices equipped with the corresponding slot.

As the main PROFIBUS station, DPM-MC2 was developed based on the EN50170 standard.

2. Technical features

Installation and removal: DPM-MC2 communication card can only be installed and removed when the device is powered off.

Indicator: With function indicator and control indicator, it is convenient for users to understand the working status of the communication card.

Connections and interfaces: The plug connector and connector allocation comply with the Profibus standard (EN50170) and provide only the transceiver signal and the power terminal for the line terminal.

Power terminals: including DGND(0V, pin 5) and VP(+5V, pin 6), are only used to supply power to the cable terminal, not for other purposes.

Bus connections: Bus segments must be terminated at both ends, each bus segment has no more than 2 bus terminals active, and at least one of them must be powered by the bus station.

3. Maintenance and warranty

Repair: Repair of DPM-MC2 communication cards can only be done by the manufacturer or authorized repair center. If necessary, please contact your local MICRO PANEL dealer or Micro Innovation's technical support department.

Warranty: Any modifications to the equipment not described in this document will not apply to the warranty.

4. Performance and functions

Manufacturing process: SMT process is used to ensure stable and reliable performance.

Protection function: Input undervoltage, overvoltage, overcurrent and other protection functions, as well as output short-circuit, overcurrent, overvoltage and other protection functions.

Remote control: Supports remote switching, remote regulation of voltage, current and other functions.

5. Application field

DPM-MC2 communication card is widely used in industrial automation control, communication equipment, LED lighting, household appliances and other fields, providing efficient, stable and reliable power supply for these devices.

6. Price information

Prices for Eaton DPM-MC2 communication cards are subject to change based on market conditions and sales channels, it is recommended to contact the seller or manufacturer directly for the latest quote.

In summary, Eaton Eaton's DPM-MC2 Communication Card is a powerful, stable communication card for the MICRO PANEL MC2 family of devices and is used in a wide range of applications.
