Foxboro P0973JN A4H124-24FX Network Switch
The Foxboro P0973JN A4H124-24FX is a high-performance network switch designed for industrial automation and control systems. Here is a detailed description of this switch:
Main features:
High performance: With an exchange capacity of up to 17.6 Gbps, it can easily handle large amounts of network traffic and ensure high efficiency of data transmission.
Large-capacity ports: Provides 24 10/100 Ethernet ports and 4 Gigabit Ethernet uplink ports to meet the connection requirements of various devices and support high-speed uplink connections.
Multi-layer packet classification and priority queuing: Priority processing can be performed according to different types of network traffic, ensuring high priority transmission of critical service data.
Power redundancy function: When connected to optional external devices, the power redundancy function automatically assumes the role of power supply when the internal power supply fails, ensuring uninterrupted network traffic.
Technical parameters:
Number of ports: Although the previous mentioned is 24 10/100 Ethernet ports and 4 Gigabit Ethernet uplink ports, but another data indicates that 24 gigabit Ethernet ports and 4 Gigabit Ethernet ports, the specific product shall prevail.
Exchange capacity: According to the data, the exchange capacity can reach 128Gbps (another data mentions 17.6Gbps, which may be related to different models or configurations).
Forwarding rate: 95Mpps.
Cache: 12MB.
Supported protocols: TCP/IP, IGMP, SNMP, RMON, STP, VLAN, etc.
Switching modes: storage-forwarding and pass-through are supported.
Physical specifications:
Dimensions: 440mm x 220mm x 44mm.
Weight: 3.5kg.
Power supply: AC 100-240V, 50-60Hz.
Power consumption: 50W.
Operating temperature: 0℃~40℃.
Storage temperature: -40℃~70℃.
Working humidity: 10%~90% (non-condensing).
Storage humidity: 5%~90% (non-condensing).
Application scenario:
Suitable for medium and large enterprise networks, it can also be used to build local area networks (Lans) or wide area networks (Wans) in industrial automation systems to support communication between devices.
It is widely used in data centers, enterprise offices, campus networks and other scenarios to meet various network requirements.
Management and standards compatibility:
It supports in-band and out-of-band management and can be configured and managed through Telnet, Enterasys Networks' NetSight management application, or WebView.
It complies with IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z and other standards.
Please note that the above information may vary depending on the product model, configuration, or production batch, depending on the actual product.
Foxboro P0973JN A4H124-24FX Network switch
Foxboro P0973JN A4H124-24FX Network switch
Foxboro P0973JN A4H124-24FX Network switch
Foxboro P0973JN A4H124-24FX Network switch
