The Triconex 3721 analog input module (0-5 VDC, 32 points) features and specifications are as follows:

Overview:

The Triconex 3721 is an analog input module for industrial automation and control systems, especially where high-precision data acquisition and monitoring is required.

Input characteristics:

Voltage range: 0 to 5 VDC

Input points: 32 differential, DC coupling

Resolution: 12 - or 14-bit programmable to provide high-resolution data acquisition and ensure data accuracy.

Performance parameters:

Input update rate: 10 ms, ensuring fast data update and processing.

Accuracy: From 0°C to 60°C, < 0.15% of FSR, providing high precision measurement.

Common mode suppression: -85 dB (DC -100 Hz), enhanced anti-interference ability.

Input overrange protection: 150 VDC/115 VAC continuous, effectively protecting the module from damage.

Design and function:

Each input channel receives variable voltage signals from each point, converts them into digital values, and transmits them to the main processor module.

The hot standby function allows online replacement of faulty modules, improving system reliability and availability.

Provides complete, continuous diagnostics, and diagnostic failures on any channel activate the module's fault indicator, which in turn activates the case alert signal.

Physical characteristics:

Weight: 1.36 kg

Shipping weight: 4 kg

Installation and connection:

Modules require a separate external terminal panel (ETP) that has a cable interface to the Tricon backplane.

Each module has mechanical keys for proper installation in the Tricon chassis.

Other features:

Two independent 1x20 bipolar multiplexers are available for general purpose switching, including temperature measurement.

Automatic connection to the 3700A Series host backplane and optional DMM via an analog backplane connection relay.

In summary, the Triconex 3721 Analog Input module (0-5 VDC, 32 points) is a high-performance, high-precision analog input module for a variety of industrial automation and control systems, providing fast and accurate data acquisition and monitoring capabilities.

Triconex 3721 Analog input module 0 - 5 VDC, 32 Point

Triconex 3721 Analog input module 0 - 5 VDC, 32 Point

Triconex 3721 Analog input module 0 - 5 VDC, 32 Point

Triconex 3721 Analog input module 0 - 5 VDC, 32 Point

Triconex 3721 Analog input module 0 - 5 VDC, 32 Point
