1.Warranty time: 1 year

2.Delivery time: 3-5 days

3.Product quality: new or discontinued second-hand

1. We are a global trading company, we have a large stock of spare parts, we also produce energy storage batteries

2. Our main sales products are industrial automation control equipment accessories, such as: controller board, processor module, communication module, input and output module, power module (various circuit boards and cards), touch screen, servo driver, servo motor, sensor, cable......

3. We can not only provide new products, but also supply cold and discontinued spare parts, all the discontinued parts will go through strict testing to ensure the reliability of product performance, so that customers can buy and use at ease

4. For more information, please contact us: Contact: Amy | Email: saul01@qq.com | Tel(WhatsApp/Wechat): +86-15359298283



Information about GE IS200EPSMG1A EX2100-POWER SUPPLY is as follows:


Product Overview:

The GE IS200EPSMG1A is an exciter source module (EPSM) developed by GE based on the Mark VI Turbine Control System.

The module is mainly used for EX2100 excitation control system and EX2100 regulator control.

Module classification:

EPSM Group 1 (EPSMG1) : Used for the excitation control system.

EPSM Group 2 (EPSMG2) : Used for regulator control.

Internal structure:

The EPSM consists of two main parts: a step-down regulator and a push-pull inverter.

Step-down regulator: Converts input voltage to 50V DC intermediate voltage.

Push-pull inverters: Use the intermediate voltage to generate the necessary multiple output voltages and provide high voltage isolation between the input voltage source and the output of the control system.

Functional application:

Excitation control System Application: The EPSMG1 converts the 125V DC voltage from the power distribution module (PDM) to the voltage required for EX2100 excitation control.

Regulator control applications: EPSMG2 converts the DC bus voltage to the voltage needed to control the EX2100 regulator.

Power supply characteristics:

The EPSMG1 provides +5V DC, 15V DC, and 24V DC power supplies for the control component backplane.

External modules are also powered by EPSMG1, including the fan, magnetic disconnection module, pry bar module, ground detector module and field voltage/current module, using 24V DC power supply.

System compatibility:

The module is compatible with GE's SIS control system solution, which is based on the TRICON Triple Module Redundancy (TMR) architecture's redundant fault-tolerant control system platform with three main processors and a triple design of all I/O signals.

Origin and Brand:

Brand: GE

Origin: USA

Please note that the above information is based on currently available information, and specific details and applications may vary by product version and specific environment. For more technical specifications or application guidance, you are advised to refer to official documents or contact GE technical support.

GE IS200EPSMG1A EX2100-POWER SUPPLY

GE IS200EPSMG1A	EX2100-POWER SUPPLY(图1)
