The Bently 167699-02 190065A Universal Device monitor is an instrument designed to continuously monitor and protect equipment used in a variety of applications and industries. Here is a detailed overview of the monitor:


Product features:

Low cost, ideal solution for general-purpose machines and processes.

Provide the ability to benefit from ongoing monitoring and protection.

Equipped with 24-bit ADC conversion function.

Sensor input:

Users can configure channels 1 through 4 to accept input from acceleration, speed, or displacement sensors.

Sensor channel types include acceleration or reciprocating acceleration, speed or reciprocating speed, radial vibration (axial vibration), thrust (axial displacement of the shaft), position, and speed.

Vibration full scale ranges from 20 to 500 m/s² (2 to 50 g) peak and effective values.

Input/Output:

Provides 4 vibration/position/speed inputs and 4 temperature inputs.

Each temperature input supports type E, J, K, and T thermocouples, as well as 2 or 3-wire rds.

It offers 6 relay outputs, 4 4-20mA logger outputs, and a dedicated buffer output.

Configuration and Software:

With the 1900 configuration software, users can configure relay contacts to open or close based on the OK, alarm, and danger states of any channel or combination of channels.

Users can provide data from any variable on any channel for any logger output.

A dedicated buffer output can provide a signal for each sensor input.

Communication:

Gateway option with support for MODBUS, allowing the monitor to provide static variables, status, event list, time and date information directly to any MODBUS client.

MODBUS communication is supported over Ethernet and a software-configurable RS232/485 serial port.

Environmental parameters:

Operating temperature: -20 to +70 ºC (-4 to +158 ºF).

Storage temperature: -30 to +90 ºC (-22 to +194 ºF).

Humidity: High 95% for operation and storage, no condensation.

Others:

Bias voltage: -24 V.

To sum up, the Bently 167699-02 190065A universal device monitor is a comprehensive and flexible monitoring device suitable for a variety of industrial application scenarios.
