ACROMAG 651T-0600 two-wire isolator
I. Product overview
The ACROMAG 651T-0600 Dual Wire isolator is an industrial automation product manufactured by ACROMAG that is designed to process current input signals and provide isolated current outputs. The isolator is available in a single-channel configuration and supports DC current input and output from 4 to 20mA.
Two, the main characteristics
Complete isolation: Provides complete isolation from input to output and channel to channel to ensure the safety and stability of signal transmission.
Very low input load: The load on the input signal is very low, ensuring the accuracy and reliability of the signal.
Convenient two-wire loop power supply: The two-wire loop power supply design simplifies the power wiring and reduces the cost.
Output current detection resistor: Equipped with a precision 10 ohm detection resistor, easy to monitor the output signal without interfering with the field wiring.
Wide ambient operation: Suitable for a variety of industrial environments with RFI, EMI, ESD, EFT and surge protection, as well as low temperature drift and wide ambient temperature operation.
3. Technical parameters
Input/output range: 4 to 20mA DC input; 4 to 20mA DC output.
Power requirements: 12 to 36V DC (loop powered) dual-wire transmitter.
Accuracy: ±0.1% of output range.
Error: Includes the combined effects of isolator repeatability, hysteresis, end point linearity, and adjustment resolution.
Weight: 0.25 pounds.
4. Application field
ACROMAG 651T-0600 two-wire isolators are widely used in industrial automation, process control, energy management, building automation, transportation systems, environmental monitoring and medical equipment. It can help users achieve precise control and management of production lines, mechanical equipment, energy systems, building interior environments, traffic signals, environmental monitoring equipment and medical equipment.
5. Installation and maintenance
The isolator is mounted on a DIN rail with removable plug-in terminals for easy installation and replacement without removing wiring. In addition, each channel includes an LED loop power indicator for easy troubleshooting and monitoring.
Vi. Summary
ACROMAG 651T-0600 two-wire isolator is a powerful and stable industrial automation product. Its complete isolation, extremely low input burden, convenient two-wire loop power supply, output current detection resistance and wide ambient operation make it able to provide accurate and reliable signal transmission and control functions in a variety of industrial environments. At the same time, its wide range of applications and convenient installation and maintenance methods also make it an ideal choice in the field of industrial automation.
